Regardless of your formal training or modeling task, ANSYS SpaceClaim unique toolset allows the users to create concepts and edit 2D and 3D models that were created in other CAD software. The direct product modeling paradigm of ANSYS SpaceClaim frees the users from the constraints of traditional concept modeling allowing you to focus better on your product design rather than the technology itself. With ANSYS SpaceClaim it is easy and pretty much straightforward to create or modify any 2D or 3D file. Ease of useĪNSYS SpaceClaim is said to be one of the most user-friendly CAD tools that anyone can use with ease as it requires minimal training and the layout is neat and modern. The integration and importing of any geometry in one environment allow for minimal time loss. The user can easily share their ideas with R&D engineers, customers, CAE analysts, and other team members. SpeedĪNSYS SpaceClaim is well known for its speed as it can create, repair and edit 2D and 3D CAD models with an efficient fashion. ANSYS SpaceClaim has several benefits over its predecessor some of which are discussed below. The general interface of ANSYS SpaceClaim Why ANSYS SpaceClaim over Design modeler?ĪNSYS design modeler was the primary 3D modeler for the software until the acquisition of SpaceClaim from ANSYS. With its simplicity and ease of use, ANSYS SpaceClaim helps the user carry out their simulations in the most effective manner. SpaceClaim is built upon direct modeling technology and can remove various geometry problems associated with 3D CAD operations such as concept and design modeling, preparing CAD files and complete model editing. ANSYS SpaceClaim is an alternative to the ANSYS design modeler and set to become the primary ANSYS 3D modeling application in the newer version of ANSYS. SpaceClaim was acquired by ANSYS from SpaceClaim Corporation in 2014.

How to start ANSYS SpaceClaim before workbenchĪNSYS SpaceClaim is a multipurpose 3D modeling and designing an application that is used to provide efficient solutions to common modeling tasks.How to start ANSYS Workbench before SpaceClaim?.How to import SpaceClaim Geometry into Mechanical APDL.Importing SpaceClaim Geometry into the Design Modeler.Importing CAD files into SCDM (SpaceClaim Direct Modeler) using Workbench.
